型号 |
层数 |
筛面规格W×L(m) |
筛面面积(㎡) |
筛孔尺寸(mm) |
生产能力(t/h) |
电机功率(Kw) |
BLS1861 |
1 |
1.8×6.1 |
10.98 |
0.5-13 |
50-100 |
22kw |
BLS2173 |
1 |
2.1×7.3 |
15.33 |
0.5-13 |
50-110 |
30Kw |
BLS2473 |
1 |
2.4×7.3 |
17.52 |
0.5-13 |
150-300 |
30Kw |
BLS2461 |
1 |
2.4×6.1 |
14.64 |
0.5-13 |
150-280 |
30Kw |
BLS3061 |
1 |
3.0×6.1 |
18.3 |
0.5-13 |
180-330 |
37Kw |
BLS3073 |
1 |
3.0×7.3 |
21.9 |
0.5-13 |
240-380 |
37Kw |
BLS3661 |
1 |
3.6×6.1 |
21.96 |
0.5-13 |
240-400 |
37Kw |
BLS3673 |
1 |
3.6×7.3 |
26.28 |
0.5-13 |
290-480 |
45 Kw |
2BLS2461 |
2 |
2.4×6.1 |
29.28 |
上层3-50 下层0.5-13 |
180-520 |
37Kw |
2BLS3073 |
2 |
3.0×7.3 |
43.8 |
300-1000 |
55Kw |
|
2BLS3061 |
2 |
3.0×6.1 |
36.6 |
250-800 |
55Kw |
|
2BLS3661 |
2 |
3.6×6.1 |
43.92 |
300-1000 |
55Kw |
|
2BLS3673 |
2 |
3.6×7.3 |
52.56 |
350-1200 |
75Kw |
