型号 Model |
主机功率 Motor KW |
粉碎口径 Cutting Chamber |
旋转刀片数(把) Cutting Knives |
固定刀片数(把) Stationary knives |
出料网孔 Screen Holes(Φ) |
GF46/60 |
22 |
400x600mm(19”x24”) |
3x2 |
2x2 |
3~25mm (1/8”~1”) |
GF50/60 |
30 |
500x600mm(20”x24”) |
3x2 |
3x2 |
|
GF60/100 |
75 |
600x1000mm(24”x40”) |
5x2 |
3x2 |
|
G80/160 |
110 |
800x1200mm(32”x47”) |
7x2 |
3x2 |
|
G80/200 |
160 |
800x2000mm(32”x60”) |
7x4 |
3x4 |
型号 Model |
粉碎量(公斤/小时) Out put Max Kg/h |
自动出料风机(功率) Blower Power (KW ) |
重量 Wright(Kg) |
给料口尺寸 Hopper Opening |
长x宽x高 Length x Width x Height(L x W x H) |
GF46/60 |
200~300 |
2.2-7.5 |
3000 |
400x600mm(19”x24”) |
1500x1950x2000mm(60”x79”x80”) |
GF50/60 |
300~400 | 4-11 |
4500 | 500x600mm(20”x24”) |
1820x1500x2200mm(72”x60”x87”) |
GF60/100 |
600~800 |
5.5-18.5 |
9000 |
600x1000mm(24”x40”) |
2300x2200x3000mm(90”x87”x118”) |
GF80/160 |
800~1100 |
11-30 |
12500 |
800x1200mm(32”x47”) |
2550x2400x3300mm(100”x95”x130”) |
GF80/200 |
1000~2000 |
15-37 |
16000 |
800x2000mm(32”x60”) |
3300x2400x3300mm(130”x95”x130”) |
